Supplies BUTTERFLY VALVE DOUBLE ECCENTRIC,DOUBLE FLANGED,FLANGE ADAPTOR.
Project location :NORTH REFINERIES IRAQ. (ش.ع)شركة مصافي الشمال
Client :MINISTRY OF OIL/NORTH REFINERIES CO. (ش.ع)شركة مصافي الشمال
Contract Value (US$) :(US$): 0
Contract Duration: 180 Days
Contract Start Date:2024-01-05
Contract Completion2024-06-09
Scope of work:-
AL KHATAB AL MUTAHIDA Co. had been contracted with (MINISTRY OF OIL/NORTH REFINERIES CO. (ش.ع)شركة مصافي الشمال)(PO) to Supplies BUTTERFLY VALVE DOUBLE ECCENTRIC,DOUBLE FLANGED,FLANGE ADAPTOR.
The contract contains the following activities:
|
No: |
Code |
Description |
Materials |
Q-ty |
|
1 |
DN800 PN16 |
BUTTERFLY VALVE DOUBLE ECCENTRIC, DOUBLE FLANGED According to the Design: DIN EN593; Flange End: DIN EN1092-2; Face to Face: EN558-1 series 14; DIN 3202/2-F4; BS EN593; Body & Disc: GGG40-50 Ductile Iron; Gasket on the Disc: EPDM; Bushing: Bronze Retaining Ring on the Disc: ST37 Steel / Body Welding Surface Seat: AISI 308 St. Steel Stems: X20Cr13 (AISI420) St. Steel / Screws on the valve: St. Steel in A2 / Screws on the Gearbox: 8.8 Galvanized Coating: RAL5005 Thermoplastic Powder Coating 300-600 microns (internal&external) Operation: Handwheel / Handwheel: ST37 Steel |
psc |
20 |
|
2 |
DN800 PN16 |
90˚ DİRSEĞİ ADAPTÖR PVC |
psc |
10 |
|
3 |
DN800 PN16 |
FLANGE ADAPTO PVC |
psc |
15 |
|
4 |
DN800 PN16 |
TE FLANGE ADAPTOR |
psc |
8 |
|
5 |
DN800 PN16 |
Ductile pipe accessories
|
psc |
30 |
|
6 |
DN800 PN16 |
Iron pipe accessories
|
psc |
12 |
